Winco 9000W Tri-Fuel Single-Phase Portable Generator - Vanguard Engine

Call for Availability and Shipping

The WINCO HPS9000VE tri-fuel generator is a great value by combining great components and excellent electrical performance. The Briggs and Stratton Vanguard is commercial grade and designed to hold up under the most demanding conditions. The V-twin 480CC engine design provides smoother power than single cylinder engines. This generator produces 8000 watts of power and at less than 6% total harmonic distortion is safe for sensitive loads like furnaces, TV’s and computers.

FEATURES

• Briggs & Stratton Vanguard Engine - Premium grade Vanguard engines are application engineered to power equipment that works for a living.
• Tri-Fuel - Designed to easily run and transition between three fuels; natural gas, LP Gas and gasoline.
• Low Oil Protection - In the event there is a low oil level, the engine will shut down to protect the engine from damage.
• Gallon Fuel Tank - The EPA-approval steel fuel tank design eliminates hydrocarbon emissions.
• CSA & EPA Approved - Winco takes the time to engineer products to have the certification that you need.
• 100% Load Tested - Every generator is fully tested prior to leaving Winco's facility.

ENGINE SPECIFICATIONS

• ENGINE BRAND: BRIGGS & STRATTON
• ENGINE MODEL: VANGUARD
• ENGINE STARTER: RECOIL/ELECTRIC
• ENGINE SPEED: 3600 RPM
• ENGINE CYLINDERS: V-TWIN
• DISPLACEMENT/TYPE: 480 CC / OHV
• FREQUENCY REGULATION: +/- 3%
• LOW OIL PROTECTION: STANDARD
• RECOMMENDED OIL: 10W-30
• OIL CAPACITY: 1.4 QTS
• FUEL TANK: 7 GAL
• FUEL GAUGE: YES
• FUEL USE GASOLINE: 1.3 GAL/HR
• FUEL USE NATURAL GAS: 180 FT(3)/HR - 183,600 BTU/HR
• FUEL USAGE LP GAS: 1.9 GAL/HR - 173,853 BTU/HR
• ENGINE WARRANTY: 2 YRS RESIDENTIAL

UNIT SPECIFICATIONS

• STARTING WATTS: 9,000
• RUNNING WATTS: 8,000
• RUNNING AMPS @ 120 VAC (Derate 20% for Natural gas): 66.7
• RUNNING AMPS @ 240 VAC (Derate 20% for Natural gas): 33.3
• VOLTAGE REGULATION: CAPACITOR +/-5%
• MAIN CIRCUIT BREAKER: 35 AMP, 240 VOLT
• NEUTRAL BONDED: YES
• 120 VOLT RECEPTACLES: (2) NEMA 5-20 20A (GFCI)
• 120/240 VOLT RECEPTACLES: (1) NEMA L14-30R 30A
• MOTOR STARTING (CODE G): 4 HP
• DBA @ 7 METERS: 77
• TOTAL HARMONIC DISTORTION: <6%
• INSULATION CLASS: H
• PROTECTIVE ROLL FRAME: 1.25" DIA 14 GA STEEL
• ASSEMBLED IN: USA
• EPA APPROVED: YES
• CARB APPROVED: NO
• CSA APPROVED: YES
• UNIT WARRANTY: 2 YR RESIDENTIAL
• DIMENSIONS: 32.75" x 22.5" x 22"
• NET WEIGHT: 202 LBS
• SHIPPING DIMENSIONS: 33" x 25" x 27"
• SHIP WEIGHT: 272 LBS
