BOSCH

Bosch D-TECT200C 12V Max Professional Wall and Floor Scanner Radar Detection for Live Cables Metal PVC and Wood Studs with Leakage Detection

Only 1 left
SKU: D-TECT200C
$1,199.00 USD

Description

See Through Concrete and Walls with Advanced Radar Precision

Eliminate the guesswork on your jobsite with the Bosch D-TECT200C 12V Max Wall/Floor Scanner. Powered by ultra-wideband radar technology, this professional detection tool offers superior accuracy compared to standard stud finders, allowing you to locate live and non-live cables, metal, plastic pipes, and wooden substructures with ease. With a detection depth of up to 7.9 inches, it is an essential instrument for contractors needing to avoid costly strikes in concrete, masonry, and drywall. The device also features specialized leakage detection, helping you quickly identify the source of moisture in walls before it becomes a major structural issue.

Designed for seamless documentation and ease of use, the D-TECT200C features a vibrant 3.5-inch color display and an intuitive user interface that clearly illustrates detected objects. The innovative "Spot View" function allows for precise scanning in tight corners where traditional movement is impossible. For reporting, the integrated screenshot feature and USB-C port make it simple to transfer data to a PC for further analysis. Built to withstand tough environments with an IP 5X rating, this kit runs on the reliable Bosch 12V Max Lithium-Ion battery system for outstanding runtime and performance.

Key Features

  • Advanced Radar Technology: Delivers precise identification of material types including metal, plastic, and wood for reliable detection.
  • Deep Detection Range: Scans up to 7.9 inches deep to locate objects hidden within thick concrete or masonry walls.
  • Leakage Detection: Quickly identifies potential leaks by detecting moisture sources within wall structures.
  • Spot View Function: Enables instant measurement and detection in small, confined spaces or corners without needing to move the tool.
  • Smart Documentation: Capture screenshots of scan results and transfer them easily via USB-C or SD card for analysis.
  • Multiple Object Views: Offers four different view modes to convey the best results for various structural situations.
  • High-Visibility Display: Features a large 3.5-inch color screen for easy reading of complex data and object illustrations.
  • Universal Detection: Accurately finds live and non-live cables, rebar, metal pipes, plastic pipes, and wooden studs.
  • 12V Max Power: Compatible with the Bosch 12V Max Li-ion battery platform for extended runtime and efficiency.

What's Included

  • (1) D-TECT200C 12V Max Wall/Floor Scanner
  • (1) 12V Max Lithium-Ion 2.0 Ah Battery (BAT414)
  • (1) 12V Max Battery Charger (GAL12V-20)
  • (1) USB Cable
  • (1) Soft Pouch

Specifications

Battery Voltage 12V Max
Max Detection Depth (Ferrous Metal) 7.9 in.
Max Detection Depth (Non-Ferrous Metal) 7.9 in.
Max Detection Depth (Copper Wiring) 3.125 in.
Operating Temperature 14°F to 95°F
Display Size 3.5 in.
IP Rating IP 5X
Length 4.5 in.
Height 9.5 in.
Weight 1.41 lbs
Connectivity USB-C, SD Card Slot
Pro-Tip: When working in tight spaces where you cannot slide the scanner across the surface, switch to "Spot View." This mode allows the radar to analyze the material directly behind the tool without requiring movement, ensuring you can still check for hazards in corners or narrow framing.
