BOSCH

Bosch Laser Level GLL40-20G 40 Foot Green Beam (Self Leveling VisiMax Cross Line Layout Alignment Tool Kit MM2 Flexible Clamp Mount Case)

Only 3 left
SKU: GLL40-20G
$127.00 USD

Description

Bosch Promtional Logo Logout

Professional Green-Beam Self-Leveling Cross-Line Laser Level System with Multi-Axis Clamp Mount

The Bosch GLL40-20G is an industrial-grade self-leveling cross-line laser level engineered to project ultra-bright horizontal and vertical layout references with a reliable 40-foot working range for precise interior construction sizing. Driven by an integrated VisiMax electronic thermal monitoring platform, this Class 2 laser automatically optimizes green diode brightness up to twice the visibility of red beams while protecting internal mechanisms against thermal degradation. The compact layout instrument achieves an accuracy threshold of ±5/16-inch at 30 feet, featuring an IP40 protection rating alongside a Smart Pendulum system that automatically checks for out-of-level conditions up to 4 degrees and locks securely to safeguard internal components during jobsite transit.

Best Used For:

  • Commercial Cabinetry Alignment: Levelling long-run cabinet bases and plumbing wall-mounted storage units accurately across interior layouts.
  • Wall Tile and Backsplash Grid Layouts: Projecting crisp perpendicular reference lines to map out ceramic or stone tile layout lines over vertical surfaces.
  • Residential Wood and Metal Framing: Squaring vertical track positions and plumbing wall stud locations across residential basement additions.

Key Performance & Safety Features

  • VisiMax Dynamic Diode Control: Real-time heat sensor balancing system regulates diode power metrics to optimize laser line illumination while preserving battery runtime.
  • High-Visibility Green Beam Matrix: Delivers up to 2X greater optical visibility compared to standard red-beam options for reliable daylight processing.
  • Smart Pendulum Auto-Leveling: Internal gravity pendulum self-corrects orientations within a 4-degree arc and displays a warning signal when pushed out of alignment.
  • MM2 Flexible Mounting Device: Included multi-surface mounting clamp features a 360-degree rotating neck to secure the chassis onto studs or pipes from 1/2 inch to 2-1/4 inches thick.
  • Secure Pendulum Transport Lock: Internal mechanism clamps firmly when powered down to protect the sensitive calibration setup from field vibration shock.

What's Included

  • (1) GLL40-20G Green-Beam Self-Leveling Cross-Line Laser
  • (1) MM 2 Flexible Mounting Device
  • (1) Heavy-Duty Protective Carrying Pouch
  • (2) AA Batteries

Technical Specifications

Brand Name: Bosch
Model Number: GLL40-20G
Tool Component Classification: Self-Leveling Cross-Line Laser Level
Maximum Optical Working Range: Up to 40 ft.
Leveling Accuracy Rating: ±5/16 in. @ 30 ft.
Self-Leveling Pendulum Arc: Up to 4 Degrees
Laser Diode Profile Class: Class 2 (500 nm - 540 nm)
Ingress Protection Rating: IP40 Rating Standard
Mount Threading Interface: 1/4-20 Thread Path
Operating Temperature Window: 41°F to 104°F
Material Metallurgy Core: Plastic Composite Housing Core
Chassis Physical Weight: 1/2 lbs.
Chassis Physical Dimensions: 3-1/5 in. L x 2-3/10 in. W x 3-1/5 in. H

Pro-Tip: When working inside brightly lit rooms or across spaces with ambient sunlight filtration, place a dedicated target plate or raw structural stock at your 40-foot layout boundary. Intersecting the high-visibility green cross-lines directly against a targeted edge surface increases visual clarity and simplifies level verification before securing hardware elements.
