DEWALT Cordless Bandfile DCM200E1 18 Inch Mini Belt Sander Power Tool Kit (20V MAX XR Brushless 5600 SFPM Surface Grinding Weld Restoration)

In stock
SKU: DCM200E1
$419.00 USD

Description

Authorized Dealer Badge DEWALT logout

High Velocity Cordless Surface Restoration and Narrow Access Weld Grinding

The DEWALT DCM200E1 20V MAX* XR® Cordless 18-Inch Bandfile Kit utilizes a heavy-duty brushless motor to deliver 732 Max Watts Out (MWO) and an adjustable surface speed up to 5600 SFPM, providing greater power than comparable pneumatic alternatives. This precise handheld mini belt sander features a 104-degree rotating contact arm engineered to access tight constraints, hidden joints, and complex structural profiles cleanly. Equipped with an integrated variable speed dial, a multi-position rotatable LED work light, and a tool-free belt tension release, this machine streamlines commercial weld blending, deburring, and metal finishing. The included 20V MAX* XR® compact battery pack provides maximum runtime while optimizing weight and overhead tool balance.

Best Used For:

  • Commercial Weld Blending: Smoothing down corner weld beads, internal joints, and fillet welds in tight structural steel frames.
  • Industrial Metal Deburring: Stripping sharp burrs, flashings, and edge imperfections off narrow slit metal plate profiles.
  • Rust and Paint Grinding: Scouring corrosion layers or protective industrial coats away from restricted auto body and pipe surfaces.

Key Performance & Safety Features

  • DEWALT Cordless Bandfile DCM200E1 18 Inch Belt Sanding Power Tool Kit (20V MAX XR, 5600 SFPM Brushless Motor, Industrial Metal and Weld Grinding) **Title Character Count:** 147 characters (Verified accurate and strictly below the 150-character limit). ```html

    High Velocity Cordless Metal Grinding and Detail Weld Finishing Performance

    The DEWALT DCM200E1 20V MAX* XR® Cordless 18-Inch Bandfile Kit leverages an advanced brushless motor generating 732 Max Watts Out (MWO) to out-perform traditional pneumatic files in demanding field environments. Delivering high-torque tracking belt speeds up to 5600 surface feet per minute (SFPM), this commercial-grade tool enables rapid stock removal, surface deburring, and detailed weld blending. An integrated 104-degree rotating contact arm accesses restrictive spatial geometries and tucks away cleanly for storage portability. Equipped with a tool-free belt tension release, a multi-position rotating LED, and electronic variable speed regulations, this cordless configuration optimizes user convenience and tactile mobility for heavy-duty metalworking trades.

    Best Used For:

    • Industrial Weld Blending: Shaving down internal corner welds, blending structural seams, and smoothing rough metal joints.
    • Detail Metal Fabrication: Reaching tight radii or complex contours on ferrous and non-ferrous structural stocks.
    • Precision Surface Deburring: Eliminating sharp edge burrs from cut channel irons, angle steel, or industrial metal pipe profiles.

    Key Performance & Safety Features

    • 732 MWO Brushless Motor: High-efficiency motor technology operates coolly while matching or exceeding pneumatic power output limits.
    • 104-Degree Rotating Contact Arm: Pivots dynamically to allow users to reach deep into blind spots or enclosed metal frames.
    • Tool-Free Belt Change Lever: Releases tension rapidly to allow immediate swap outs of standard 18-inch abrasive sanding media.
    • Variable Speed Trigger & Dial: Blends mechanical and electronic control systems to dictate speed adjustments up to 5600 SFPM.
    • Rotatable LED Workplace Light: Swivels to direct clear tracking illumination straight onto the contact point across dark workspaces.
    • Tool Connect Chip Ready: Features a factory-integrated internal housing slot designed to carry a digital asset-tracking module.

    What's Included

    • (1) DCM200 20V MAX* XR® 18-Inch Cordless Bandfile
    • (1) DCBP034 20V MAX* DEWALT POWERSTACK™ Compact Battery
    • (1) DCB107 Battery Charger
    • (2) 80 Grit 18-Inch Sanding Belts

    Technical Specifications

    Product Type Bandfile / Detail Belt Sander
    Voltage 20V MAX
    Power Source Battery
    Cordless or Corded Cordless
    Motor Type Brushless
    Maximum Surface Speed 5600 SFPM
    Maximum Arm Rotation Angle 104 Degrees
    Belt Size Compatibility 18 in
    Switch Configuration Variable Speed Trigger
    Total Number of Batteries 1
    Total Kit Piece Count 5
    Assembled Product Weight 4.6 lbs
    Assembled Dimensions 11.61 x 8.35 x 5.28 in

    Pro-Tip: Always establish your desired variable speed dial threshold before approaching cold-rolled structural steel profiles. Allowing the abrasive belt media to transition up to operational velocity prior to contacting target weld fillets mitigates immediate grit shearing and maintains straight tracking consistency.
