DEWALT

DEWALT XTREME 12V MAX 5-3/8-inch Brushless Cordless Circular Saw Bare Tool DCS512B Compact Lightweight High Performance Precision Cutting Rafter Hook LED Brake Only

Only 1 left
SKU: DCS512B
$169.00 USD

Description

Authorized Dealer Badge DEWALT logout

Execute Precision Cross Cuts Natively Across Narrow Structural Framing Timbers via Compact Brushless Blade Technology

The DEWALT DCS512B 12V MAX* XTREME™ Brushless 5-3/8-Inch Circular Saw is a lightweight cordless demolition and fabrication tool engineered for professional trim, cabinet, and framing applications. This precision-focused saw utilizes an advanced brushless motor to maintain consistent cutting velocity, achieving a maximum depth of 1-3/4 inches at 90 degrees and 1-1/4 inches at 45 degrees. Outfitted with an integrated electronic blade brake for instantaneous cycle stopping, an onboard LED cut-line illuminator, and tool-free bevel adjustment, this unit provides maximum maneuverability for high-repetition overhead tasks. **Battery and charger sold separately.

Best Used For:

  • Precision Trim Carpentry: Trimming interior hardwood casing, baseboards, and composite trim panels cleanly in confined residential jobsite areas.
  • Small Scale Framing: Executing repetitive cuts on thin dimensional lumber or wall blocking where full-sized circular saws are excessively heavy.
  • Panel and Sheet Fabrication: Sizing cabinet-grade plywood and laminated veneer board components precisely for custom shop assembly workflows.

Key Performance & Safety Features

  • High-Efficiency Brushless Powertrain: Digital motor management scales energy delivery to ensure longer runtime and reduced maintenance compared to brushed tool cores.
  • Rapid Electronic Blade Brake: Safety-engineered circuitry triggers an immediate stop to the rotating blade disc the moment the trigger lever releases.
  • Tool-Free Bevel Lever: Quick-adjust locking toggle permits rapid transition from 0 to 50 degree angle cuts without requiring additional hex keys.
  • Integrated LED Cut-Line Light: Forward-facing diode array casts a focused brightness cone onto the blade path to ensure accuracy in dark corners.
  • AirLock Dust Chute Port: Standardized extraction port connects natively to industrial vacuum manifolds to keep the cutting zone clear of debris.

What's Included

  • (1) DCS512 12V MAX* 5-3/8-Inch Cordless Circular Saw Skin
  • (1) 5-3/8-Inch 18-Tooth Carbide-Tipped Wood Cutting Blade
  • (1) Blade Change Spindle Wrench
  • (1) Snap-On Dust Extraction Chute Assembly
  • (1) Adjustable Precision Metal Rip Guide

Technical Specifications

Brand Manufacturer: DEWALT
Model Number (SKU): DCS512B
Product Type Category: Brushless Cordless Circular Saw
System Operating Voltage: 12V MAX*
Internal Motor Architecture: High-Efficiency Brushless
Blade Diameter Metric: 5.375 in
Max No-Load Speed: 3,600 RPM
Bevel Adjustment Range: 0 to 50 Degrees
Max Depth Cut 90-Deg: 1.75 in
Max Depth Cut 45-Deg: 1.25 in
Configuration Classification: Bare Tool Only (**Battery & Charger Sold Separately)
Assembled Product Weight: 6.35 lbs
Assembled Length: 15.69 in
Assembled Width: 7.03 in
Assembled Height: 8.32 in

PRO-TIP: When making finish cuts on pre-finished plywood or MDF, score your top cut-line with a sharp utility knife first to minimize splintering. Maintaining the saw base plate perfectly square against the workpiece while engaging the 3,600 RPM brushless motor ensures the carbide tips provide a burn-free, professional-grade finish natively.
