Diablo Segmented Turbo Masonry Blade DMADST1200 12 Inch Cut-Off Disc (6400 Max RPM 0.11 Kerf Concrete Rebar Brick Cinder Block Sawing)
Couldn't load pickup availability
Industrial 12-Inch Segmented Turbo Abrasive Disc for High-Speed Structural Reinforcement and Concrete Core Cutting
The Diablo DMADST1200 12-Inch Diamond Segmented Turbo Masonry Cut-Off Blade delivers professional-grade mechanical shearing precision when processing reinforced cured concrete, thick structural rebar, dense building brick, and aggregate cinder block layers. Engineered with a specialized 0.11-inch kerf thickness profile and an industrial SPEED-Edge slot configuration, this abrasive saw disc reduces rotational surface resistance to achieve up to 30% faster material removal metrics while dampening harmful machine chatter. The heavy-duty hardened core disc plate accommodates both standard 1-inch and 0.787-inch (20mm) drive spindles using the provided modular reduction bushing adapter. Certified for high-production parameters operating up to a 6,400 RPM maximum velocity rating, this versatile diamond tool accessory transitions seamlessly between water-pressurized wet cooling flows or high-friction dry utility pavement cutting environments.
Best Used For:
- Reinforced Poured Concrete Sawing: Executing high-speed linear cuts through structural foundations and slab segments containing buried steel rebar mesh reinforcement.
- Commercial Masonry Wall Openings: Slicing precise clean margins through high-density load-bearing building bricks and structural grout joints during utility placements.
- Heavy Infrastructure Drainage Trenches: Deep coring of dense aggregate cinder blocks and highway curb barriers on jobsites utilizing handheld gas or walk-behind saw machinery.
Key Performance & Safety Features
- SPEED-Edge Slot Configuration: Advanced aerodynamic body expansion cutouts isolate vibration waves while facilitating immediate hot slurry and waste dust extraction.
- 60% Taller Cutting Segments: High-profile perimeter matrix columns store an expanded volume of industrial diamonds to yield up to 4X longer service lifespans.
- Hardened Structural Disc Body: Heavy-gauge carbon steel core plate absorbs intense mechanical percussive shocks, preventing tracking warp under load.
- Constant Diamond Exposure Matrix: Optimized metallurgical bond formulation continuously releases worn abrasive grit to keep fresh diamond crystals exposed at high speeds.
- Dual Spindle Arbor Fitment: Interlocking center bore architecture matches 1-inch drive shafts directly and includes a precision-machined 20mm reduction bushing.
What's Included
- (1) Diablo DMADST1200 12" Diamond Segmented Turbo Masonry Blade
- (1) 20mm Internal Reduction Bushing
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Diablo |
| Model Number | DMADST1200 |
| Blade Diameter | 12.0 in |
| Arbor Sizes Compatibility | 1.0 in and 0.787 in (20 mm) |
| Rim Design Profile | Segmented Turbo Rim |
| Kerf Thickness | 0.11 in (2.8 mm) |
| Maximum Rotational Velocity | 6,400 RPM |
| Cutting Environment | Wet or Dry Cutting |
| Segment Height Scale | 60% Taller than Standard Blades |
| Workpiece Materials Focus | Concrete, Concrete with Rebar, Brick, Cinder Block |
| Pack Quantity | 1 Blade |
Pro-Tip: When deploying this segmented turbo blade in heavy dry masonry applications, prevent continuous abrasive friction glaze by avoiding excessive downward operator pressure. Allow the gas saw tool weight to dictate penetration speed, and periodically backup the blade out of the trench for 10 seconds to draw cool ambient air over the core segments, preventing metal core warping.
