Diablo Hammer Drill Bit DMAMM1070 5/16 Inch x 6 Inch Multi Material (Carbide Grip Point Tip Masonry Concrete Tile Wood Metal Fast Boring Tool)

Diablo DMAMM1070 5/16-Inch x 6-Inch Multi-Material Carbide-Tipped Hammer Drill Bit

The Diablo DMAMM1070 5/16-Inch x 6-Inch Multi-Material Carbide Hammer Drill Bit bores precise anchor holes through ceramic tile, poured concrete, masonry brick, structural wood, and sheet metal. Engineered with an aggressive multi-ground Grip Point carbide tip, this multi-purpose bit delivers immediate self-centering starts without wandering across glazed tile or polished metal. Featuring an Impact Strong™ 1/4-inch hex-compatible shank, 4 inches of usable drilling depth, and high-efficiency dust clearing flutes, this versatile hole cutter equips electricians, plumbers, and commercial remodelers with seamless, one-bit drilling across mixed jobsite substrates using impact drivers, standard drills, or hammer drills.

Best Used For:

• Masonry & Heavy Anchor Installation: Drilling 5/16-inch anchor clearance holes for heavy-duty sleeve anchors, lag shields, and concrete fasteners.
• Tile-to-Substrate Fixture Mounting: Boring through decorative ceramic, porcelain, and stone tile into underlying wall framing without cracking glazed faces.
• Multi-Layer Wood & Metal Framing: Sinking clean pilot holes through steel studs, sheet metal flashing, and structural lumber in a single continuous pass.

Key Performance & Safety Features

• Multi-Ground Grip Point Tip: Precision-sharpened carbide tip bites into smooth surfaces on contact to eliminate bit walking and surface scratching.
• Impact Strong™ Hex Shank: 1/4-inch quick-change hex shank absorbs severe impact driver torque loads and prevents chuck slippage in standard drills.
• Thermal-Resistant Carbide Tip: Industrial carbide braze withstands high friction heat and continuous hammer impact for extended cutting life.
• Optimized Debris Clearing Flutes: High-capacity spiral flutes extract concrete dust and wood shavings rapidly to keep the cutting tip cool.
• Universal Tool Compatibility: Operates seamlessly across cordless impact drivers, standard rotary drill drivers, and hammer drills.

What's Included

• (1) Diablo 5/16" x 6" Multi-Material Carbide-Tipped Hammer Drill Bit (DMAMM1070)

Technical Specifications

Pro-Tip: When boring 5/16-inch holes through tile into poured concrete, start drilling in rotary mode to penetrate the tile glaze cleanly; once through the tile layer, engage hammer action to rapidly penetrate the underlying concrete.
