A professional studio shot of the Freud 43-216 15/16 inch carbide-tipped insert bevel trim router bit on a white background, featuring a 1/4 inch shank, signature red non-stick coating, and a 4-sided replaceable carbide knife with a top pilot bearing for precision laminate trimming and woodworking.
Technical profile diagram of the Freud 43-216 router bit demonstrating a 45-degree bevel trim capacity on a wood workpiece, highlighting the clean geometric edges and professional surfacing finish achieved with replaceable carbide insert knives.
A professional studio shot of the Freud 43-216 15/16 inch carbide-tipped insert bevel trim router bit on a white background, featuring a 1/4 inch shank, signature red non-stick coating, and a 4-sided replaceable carbide knife with a top pilot bearing for precision laminate trimming and woodworking.
Technical profile diagram of the Freud 43-216 router bit demonstrating a 45-degree bevel trim capacity on a wood workpiece, highlighting the clean geometric edges and professional surfacing finish achieved with replaceable carbide insert knives.
Freud

Freud 43-216 15/16 Inch Carbide Tipped Insert Bevel Trim Router Bit 1/4 Inch Shank 45 Degree 4-Sided Replaceable Knife Woodworking Laminate Trimmer

Only 2 left
SKU: 43-216
$105.97 USD

Description

Freud precisely the best logo Logout

Maximize Productivity with 4-Sided Replaceable Knives for Flawless Laminate Beveling

Achieve professional, factory-quality edges on every project with the Freud 43-216 15/16" Carbide Tipped Insert Bevel Trim Router Bit. Engineered specifically for the demanding task of beveling plastic laminates, this bit features a 45-degree angle that creates a clean, softened transition on countertops, cabinet edges, and furniture. The innovative insert system utilizes solid carbide knives with four distinct cutting edges; when one edge becomes dull, simply rotate the knife to a fresh side to continue working with zero downtime. This system ensures that you are always cutting with a razor-sharp edge, resulting in a smooth finish that requires no additional filing.

This bevel trim bit is built for versatility and long-term cost savings. Instead of replacing the entire bit or waiting for sharpening services, you simply install a new replacement throwaway knife (CG01MBA3) once all four edges are spent. The bit is computer-balanced for vibration-free operation at high speeds, making it ideal for use in high-performance laminate trimmers, hand-held routers, or table-mounted setups. Whether you are a professional shop owner or a dedicated DIYer, the Freud 43-216 provides a reliable, high-precision solution for cutting all types of plastic composition materials and laminates.

Key Features

  • 4-Sided Insert Knives: Replaceable solid carbide knives feature four cutting edges for maximum tool life and minimal downtime.
  • Precision 45-Degree Bevel: Ideal for creating clean, decorative beveled edges on plastic laminates.
  • Cost-Effective Maintenance: Throwaway knife system eliminates the need for professional sharpening.
  • Versatile Compatibility: Designed for use with hand-held routers, laminate trimmers, and table-mounted portable routers.
  • Industrial Carbide Construction: High-density carbide ensures long-lasting performance in abrasive laminate materials.
  • High-Speed Balance: Engineered for smooth, chatter-free operation to prevent chipping on delicate surfaces.

What's Included

(1) Freud 43-216 Insert Bevel Trim Router Bit with 1/4" Shank and (1) Installed 4-Sided Carbide Knife

Specifications

Diameter (D) 1-23/64"
Shank Diameter (d) 1/4"
Angle (a°) 45 Degrees
Cutter Height (B) 15/64"
Overall Length (L) 2-5/8"
Bearing Diameter 3/4"
Number of Wings 2
Cutting Material Solid Carbide Insert
Application Beveled Edge on Plastic Laminates
Replacement Knife Part # CG01MBA3

Pro-Tip: To extend the life of your carbide inserts and ensure a perfectly smooth bevel, always clean the laminate surface of any excess adhesive before routing. Adhesive buildup can cause the bearing to "skip" or the blade to gum up, leading to an uneven edge. If you notice any burning or resistance, rotate to a fresh cutting edge immediately to maintain a professional finish.
