Great for tough debris conditions, industrial, construction, agriculture, landscape and general water removal containing up to 30% suspended solids. A step up from the Semi-Trash line, Koshin’s Trash Pump line is proven the world’s toughest trash pump. Pro construction contractors know that often any water accumulating on a job site contains gravel and other debris. Koshin’s highest-quality and strongest pump design mean that many of our trash pumps are the most durable under any conditions. Koshin, the world’s toughest pump!

FEATURES

• SILICON CARBIDE MECHANICAL SEALS for Increased Abrasive Resistance, Longer Life, and Less Maintenance
• EXTREME DURABILITY: Case Iron Impellers Blended with Hi-Chrome, for Extreme Durability and Erosion Resistance
• REMOVABLE FRONT COVERS: Front Covers are Removable Without Disassembly of Hoses. Easy and Quick Access, for Cleaning our Debris, or Pump Repair
• NO NEED FOR A WEAR PLATE: Volutes are Constructed of Spheroidal Graphite Ductile Iron, Eliminating the Need for a Wear Plate, Increasing Durability, and Longer Life
• DIE CAST ALUMINUM PUMP HOUSINGS: for Strength, Weight Reduction, and Portability
• ROLL CAGES: Rugged Powder Coated Roll Cages
• THREE-YEAR LIMITED WARRANTY on Pump Ends

PUMP SPECIFICATIONS

• MAX SOLIDS SIZE: 20mm (0.78″)

• CONNECTION DIA.: 50mm (2”)

• MAX TOTAL HEAD: 22m (72 ft)

• MAX DELIVERY VOLUME: 680L /min (179 USG/min)

• MAX SUCTION LIFT: 8m (26 ft)

• MATERIAL OF MECHANICAL SEAL: Sic x Sic
• MATERIAL OF IMPELLER: Hi-Chrome

• MATERIAL OF VOLUTE CASTING: FCD450
• ACCESSORIES: 1 Strainer, 3 Hose bands , 1 Wrench
• DIMENSIONS (L x W x H): 673mm x 554mm x 510mm

• GROSS WEIGHT: 53.9 kg (118.8 lbs)


ENGINE SPECIFICATIONS

• MODEL: K180

• EXHAUST VOLUME: 179cc

• RATED OUTPUT: 3.1kW/min-1(4.2PS)(4.1 HP)　/　3600rpm

• MAX OUTPUT: 3.5kW/min-1(4.8PS)(4.7 HP)　/　3600rpm

• ENGINE OIL: 15W-40 SAE (API service category SD or later)

• ENGINE OIL CAPACITY: 0.55L (0.15 USG)

• FUEL TANK CAPACITY: 3.6L (0.95 USG)

• STARTING METHOD: Recoil starter

• CONTINUOUS OPERATING TIME: Approx. 2.0 hrs
